Water Still DS 8025
water distillation unit
Professional, fully automatic water distiller with a production capacity of 25 liters per hour and an integrated
50-liter storage tank. Constructed from high-quality stainless steel, this distiller is designed to
produce high
purity distillate autonomously, eliminating the need for continuous personnel supervision.
DragLab Water Still offers unique advantages
• Durable, reliable and Low cost
• High purity distilled water - conductivity approx 2,5 μS/cm at 25 °C
• Built-in 50 litter storage tank
• Automatic water switching and power cut-off
• Electronic water level switch
• Automatic thermostatic cut-off safety system
• Hearing element made of high quality stainless steel
• All water contact materials are made of stainless steel (material no.: EN 1.4301)
• Easily accessed evaporator & storage tank for effortless cleaning and maintenance
• The unit is suitable for both bench and wall mounting.
• All parts and accessories for installation included.
• CE Certificate
• 2-years warranty
Dimensions
Technical specifications
| Capacity | |
|---|---|
| Capacity | 25 Litter / hour |
| Storage Tank | 50 Litter storage tank built-in |
| Consumption | 250 litter / hour |
| Conductivity | approximately 2,5 μS/cm at 25 ºC |
| Control technology | |
|---|---|
| Fully Automatic |
|
| Water supply | Built-in solenoid valve connection for the evaporator and cooler, with automatic switching on/off based on the water level in the evaporator tank. |
| Standard equipment | |
|---|---|
| Internal material |
|
| External material | The housing is made from galvanized steel and coated with electrostatic powder. |
| Degassing system | The unit includes a top vent for effective degassing, ensuring pyrogen-free, low-gas, and bacteria-free water. |
| Accessing interior | The evaporator and storage tanks are easily accessible for cleaning and maintenance, facilitating efficient cleaning procedures. |
| Installation | All necessary parts and accessories for installation are included. |
| distillate water withdrawal | Distillate water can be withdrawn by continuously or push mode from front tap. |
| Main switch | The device features a tube indicating water level in the storage tank. |
| Mounting | Suitable for both benchtop and wall mounting. |
| Safety | |
|---|---|
| Water | Low water level sensor with automatic power cut-off to protect the heating element. |
| Heating | Overheating cut-off |
| Degassing | pyrogen-free, low-gas, and bacteria-free water. |
| Power connection | Power cable with 5 pins three-phase CEE plug. |
| Connection | |
|---|---|
| Water inlet | The cooling water inlet is located on the right-hand side of the unit, with a diam eter of 3/4 inch (Ø 19.05 mm). |
| Water pressure range | From 2 bars to 10 bars |
| Water outlet | The cooling water outlet is located on the right-hand side of the unit, with a di ameter of 2/5 inch (inner Ø 10 mm). |
| Drainage tap | The drainage tap is located on the right-hand side of the unit, with a diameter of 2/5 inch (inner Ø 10 mm). |
| Distillate water | Distillate water can be withdrawn by continuously or push mode from front tap. |
| Power | The main connection cable on the left-hand side of the unit. |
| Electrical data | |
|---|---|
| Voltage | 380 volts, 50/60Hz |
| Watt | 18000 watts |
| Shipping information | |
|---|---|
| Customs tariff number | 8419 4090 |
| Packaging Dimension | 123 W X 77 D X 87 H (CM) |
| Net weight | 87 Kg |
| Gross weight | 98 Kg |
Order information
| Description | Model | Article number |
|---|---|---|
| Water Still – Capacity: 25 L/H, 50 L storage Tank –380V, 50/60Hz | DS 8025 | 5025.000 |
Options
| Description | Article number |
|---|---|
| Mains water inlet tap | 100 |
| Distilled water record | 200 |
| Waste water record | 300 |
| Drain tap | 400 |
| Heating element | 500 |
| Silicon hose | 600 |
